| ITEM | DESCRIPTION |
| Standards Compliance |
IEEE 802.11 n/b/g; IEEE 802.3; IEEE 802.3u; IEEE 802.3p; IEE802.3x; IEEE 802.3af |
| SDRAM |
16M Bytes |
| Flash | 2M Byte |
| Modulation | OFDM: BPSK, QPSK, 16-QAM, 64-QAM, DBPSK, DQPSK, CCK |
|
Frequency Band | America/FCC: 2.412~2.462 GHz (11 channels)
Europe CE/ETSI: 2.412~2.472 GHz (13 channels) |
| Transmission Power | IEEE 802.11b: 1/ 2/ 5.5/ 11Mbps
IEEE 802.11g: 6/ 9/ 12/ 18/ 24/ 36/ 48/ 54Mbps
IEEE 802.11n: See Below Chart
|
| Transmission Rate |
| MCS |
Guard Interval 800ns |
Guard Interval 400ns |
| 20MHz(Mbps) |
40MHz(Mbps) |
20MHz(Mbps) |
40MHz(Mbps) |
| 0 |
6.5 |
13.5 |
7.2 |
15 |
| 1 |
13 |
27 |
14.4 |
30 |
| 2 |
19.5 |
40.5 |
21.7 |
45 |
| 3 |
26 |
54 |
28.9 |
60 |
| 4 |
39 |
81 |
43.3 |
90 |
| 5 |
52 |
108 |
57.8 |
120 |
| 6 |
58.5 |
121.5 |
65 |
135 |
| 7 |
65 |
135 |
72.2 |
157.5 |
| 8 |
13 |
27 |
14.4 |
30 |
| 9 |
26 |
54 |
28.9 |
60 |
| 10 |
39 |
81 |
43.3 |
90 |
| 11 |
52 |
108 |
57.8 |
120 |
| 12 |
78 |
162 |
86.7 |
180 |
| 13 |
104 |
216 |
115.6 |
240 |
| 14 |
117 |
243 |
130 |
270 |
| 15 |
130 |
270 |
144.4 |
300 |
|
| Access Point Interfaces |
Auto MDI/MDI-X Ethernet 10/100/1000 Base-TX: RJ-45 |
| Sensitivity | IEEE 802.11b: -92dBm @ 1Mbps; -85dBm @ 11Mbps, PER < 8%
IEEE 802.11g: -88dBm @ 6Mbps; -73dBm @ 54Mbps, PER <10%
IEEE 802.11n:-90dBm@MCS8; -70dBm@MCS15, PER <10% |
| Antenna Type |
2 printed antennas (5dBi) |
| Security Systems | 64-bit / 128-bit WEP encryption; Wi-Fi Protected Access (WPA) / WPA2 |
|
Wireless Setting | Operation Mode – AP / Repeater / WDS PtP and PtMP |
|
Software/Firmware | DHCP Server / Client
Suppressed SSID
Station Separation
Wireless access control by MAC address filter (up to 50)
Web-based configuration via popular browser (MS IE, Netscape…)
Firmware upgrade and configuration backup via Web Browser
Reset to default by WebUI or by Reset button
VPN pass-through (PPTP, L2TP, IPSEC)
Traffic Measurement: Per Interface
Bandwidth Measurement: IP Range & Bandwidth Management
Backup & Restore Settings Through Web
SysLog
SNMP v1/v2c
MIB support: MIB I, MIB II (RFC-1213) and Private MIB
Support QoS(WMM)
Support Time settings
|
| Operating Environment | Operating Temperature: 0 ~ +40°C; Storage Temperature:-40 ~ +70°C;
Operating Humidity: 10% ~ 90% RH non-condensing;
Storage Humidity: 5% ~ 90% RH non-condensing |
| Power |
DC12 Volt ± 5%; 1.25A(Max.) or DC 48 Volt ± 5%; 0.4A (Max.); AC adapter AC 100V ~
240V |
| Power Consumption | 6W |
| Regulatory Approval |
CE; RoHS |
Network Management
System Browser Support |
IE / Safari / Chrome / Firefox / Opera |
| Warranty |
One year limited |
